HET 03190 - COMPACTION FACTOR APPARATUS : IS : 1199, 5515
10
COMPACTION FACTOR APPARATUS
A useful tool for workability determination of concrete mixes of very low workability such as those normally used with Concrete, compacted by Vibration. Concrete mix having maximum size of aggregate exceeding 38 mm can be tested for workability. Apparatus is complete with hoppers and receiver assembly.
It consists of two rigid conical hoppers and a cylinder mounted on a rigid metal frame. The lower openings of the hoppers are fitted with hinged trapdoors having a quick release catches. A circular metal plate is provided to cover the top of the cylinder. Supplied complete with one plaster's trowel and one tamping rod, 16mm dia x 600mm long, both ends rounded.
